5 Channel Butterfly Point Light Source High Stability Power 10mW
The U8135 multi-channel DFB light source can be used for the measurement and application of WDM CWDM devices, high precision WDM DWDM devices, optical waveguide grating array AWG devices, planar optical waveguide PLC devices, optical amplifier EDFA and other general optical fiber optics, especially for the mass production detection of couplers and planar optical waveguide PLC components.
The U8135 multi-channel DFB light source has the characteristics of high output stability, small size and fast start-up. The light source device can provide multiple channels of fixed wavelength light source output signals. Youxi Instrument can also customize the light source equipment of ITU wavelength combination such as 1523.34/1536.61/1549.32/1563.05/1573.71 nm according to customer needs.
A multi-channel DFB light source is a laser light source with multiple output channels of a fixed wavelength. It is widely used in wave division multiplexing (WDM) system, optical communication, optical sensing and other fields.
This light source is characterized by high output stability, small size, fast start and so on. It can provide multiple channels of fixed wavelength light source output signal, especially suitable for mass production detection of optical devices, such as couplers, planar optical waveguide PLC components.
Specification:
| 型号Model # | U8135 |
| Device Package | Butterfly |
| Optional Wavelength | 1523.34 / 1536.61 / 1549.32 / 1563.05 / 1573.71 |
| Wavelength Accuracy | ± 0.1 nm |
| Output Power | ≥ 8.0 mW |
| Connector Type | FC/APC |
| Bandwidth@3 dB | ＜ 0.1 nm |
| Bandwidth@20 dB | ＜ 0.5 nm |
| Output Power Stability within 15mins | ≤ ±0.005 dB |
| Output Power Stability within 8 hrs | ≤ ±0. 05 dB |
| Type of fiber | Single Mode |
| SMSR | ＞ 40 dB |
| Communication interface | USB |
| Operation Temperature | 0～+30 ℃ |
| Storage Temperature | -20～+70 ℃ |
| Dimensions | 235 mm W, 55 mm H, 320 mm D |
| Weight | 3.0 kg |
Product Tags:
|
|
5 Channel Butterfly Point Light Source High Stability Power 10mW Images
|
